TRIDENT iGW610R-G6

Immersion GPU Server

The CIARA TRIDENT iGW610R-G6 rises to the challenge of delivering exceptional AI and HPC performance.

1U
Dual 4th and 5th Gen Intel® Xeon® Scalable Processors
4 x FHFLDW PCIe 5.0 x16 GPU cards
Up to 8TB DDR5-5600 MT/s memory
4 x Hot-swap E1.S EDSFF and 2 x M.2
ASPEED AST2600 management
3000W (1+1) Redundant 80 PLUS Titanium Power Supply
Perfect for HPC, AI, Edge Computing and more

Product Overview

The CIARA TRIDENT iGW610R-G6 rises to the challenge of delivering exceptional AI and HPC performance in a compact, ultra-dense 1U form factor. Purpose-built for single-phase immersion cooling, this immersion-born server supports a range of powerful GPUs such as NVIDIA RTX 6000 Pro Blackwell, H200 NVL, H100 NVL, and L40S including other PCIe-based accelerators.

Now featuring hot-swappable E1.S drives up to 64TB in storage, it adds even more flexibility for data-intensive workloads. This allows organizations to scale smarter, faster, and more efficiently than ever before.

Key Features and Benefits

Perfect For

HPC

AI

AI Inference

AI Training

Edge Computing

Data Analytics

Research

Trademarks: Intel, the Intel logo, Intel Core, Intel Inside, the Intel Inside logo, Intel vPro and Xeon are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries. Other company, product or service names may be trademarks or service marks of others.

Trademarks: AMD, and the AMD Arrow logo, AMD EPYC, Ryzen, Threadripper and combinations thereof are trademarks of Advanced Micro Devices Inc.

Tech Specs

	1U - 4 GPU (TRIDENT Immersion-born)
Product Category	Immersion GPU Server
Form Factor	1U
Cooling System	Single-phase Immersion Cooling
Power Supply	1+1 Redundant CRPS 3000W AC - 80 PLUS Titanium Power Supply
Dimensions (L x W x H)	33.46" x 21.06” x 1.75” 850mm x 535mm x 44.5mm
Estimated Weight	72 lb 32.6 kg
Processor	Dual 4th and 5th Gen Intel® Xeon® Scalable Processors, TDP up to 350W
Heatsink	Immersion Cooling Custom Heatsink
TIM	Indium Foil
Memory	16+16 DIMM slots (2DPC) 288-pin DDR5 RDIMM/ RDIMM-3DS 8-channel memory architecture RDIMM: 96GB RDIMM-3DS: 2H- 128 GB / 4H- 256 GB 5600 MT/s (1DPC) / 4400 MT/s (2DPC) on 5th Gen Intel® Xeon® Scalable Processors 4800 MT/s (1DPC) / 4400 MT/s (2DPC) on 4th Gen Intel® Xeon® Scalable Processors *Memory speed and capacity support varies by CPU SKU
Network Controller	1 x RJ45 Dedicated IPMI LAN port by Realtek RTL8211F
Storage	2 x M.2 (PCIe 4.0 x4), support 22110/2280 form factor [CPU2] 4 x E1.S EDSFF NVMe Drives up to 9.5mm
Expansion Slots	2 x PCIe 5.0 x16 HHHLSW 2 x OCP NIC 3.0 (PCIe 5.0 x16) 4 x PCIe 5.0 x16 FHFLDW
GPU/FPGA Capabilities	Yes (4 x GPU/FPGA)
I/O Top	2 x USB Type A (3.2 Gen1) 1 x Mini Display Port (VGA) 1 x RJ45 dedicated IPMI 1 x RJ45 (COM) 1 x UID Button w/ LED
Management	ASPEED AST2600: IPMI2.0 with iKVM and vMedia support
OCP (ORv3) Availability	NA
OS Support	Microsoft® Windows®: Server 2022 (64 bit) Linux: Red Hat Enterprise Linux Server 8.4 (64 bit) / 8.5 (64 bit) / 9.1 (64 bit) SUSE Enterprise Linux Server 15 SP3 (64 bit) Ubuntu 21.10 (64 bit) / 22.04 (64 bit) Hypervisor: VMWare® ESXi 7.0 U3g / 8.0 *RAID mode is not supported on the Ubuntu system.
